    Nikon D700 Digital SLR



The D700 extends Nikon’s range of FX format SLRs, incorporating groundbreaking technologies and performance into a discreetly-sized body. The highly sensitive 12.1 megapixel CMOS sensor provides an (extendable) ISO range of 200 to 6400 and features a self-cleaning dust-reduction unit. Its EXPEED image processing engine enables the capture of images with superb detail and tonal gradation at up to 5 fps (8 fps with the optional MB-D10 battery pack and EN-EL4a battery). The advanced Scene Recognition System delivers superior exposures and is supported by Nikon’s acclaimed 51-point AF system, which offers outstanding tracking accuracy even in low light. The selectable Picture Controls streamline in-camera image processing, saving time in post-production, and a high definition 3-inch LCD screen supports two Live View modes plus an HDMI video output. Protected by a tough, environmentally-sealed magnesium alloy body, the D700 is a perfectly-balanced DSLR that can handle the unexpected, wherever your photography takes you.











Features

  • 12.1 megapixel FX (full-frame) CMOS sensor with high signal-to-noise ratio, wide dynamic range, and built-in self-cleaning sensor unit that minimizes dust.
  • ISO 200 – 6400: extendable up to 25600 (equivalent) and down to ISO 100 (equivalent).
  • 5fps continuous shooting (8fps with optional MB-D10 battery pack with lithium-ion battery EN-EL4a or 8 AA batteries).
  • EXPEED image processing engine with 14-bit A/D conversion and 16-bit image processing for superb detail and tonal gradation.
  • Advanced Scene Recognition System combines the camera’s metering and AF sensors for precise exposures and sharply defined images.
  • Multi-CAM3500FX 51-point AF system. Individually selectable or configurable in 9-point, 21-point and 51-point coverage settings.
  • Picture Controls streamline in-camera image processing by enabling the pre-set customization of image parameters such as sharpening, contrast, brightness, hue and saturation in various color modes.
  • 920,000 dot 3-inch VGA LCD monitor with wide, 170-degree viewing angle.
  • Live View with Autofocus enables composition of images by use of the LCD monitor. Two modes are supported: Handheld or Tripod.
  • DX Crop Mode can be automatically enabled when a DX format lens is attached.
  • Quick response: approx. 40 ms shutter-lag.
  • Active D-Lighting enables superior high-contrast images by automatically applying tone compensation at the moment of capture.
  • HDMI video output interface enables connection to high-definition video systems.
  • Intuitive ergonomics with optimized button placement for fast and comfortable handling.
  • Durable Magnesium alloy body: moisture and dust resistant.
  • Wireless LAN and Ethernet support via optional Wireless Transmitter WT-4.



Specifications

Type

Single-lens reflex digital camera
Lens Mount Nikon F bayonet mount with AF coupling and AF contacts
Picture Angle Equivalent to angle produced by lens focal length (1.5 times when DX format is selected)
Effective Pixels 12.1 million
Image Sensor CMOS sensor, 36.0 x 23.9 mm; Nikon FX format
Total Pixels 12.87 million
Dust-Reduction System Image sensor self-cleaning function, Image Dust Off reference data acquisition (Capture NX 2 required)
Image Size (pixels) FX format (36 x 24) : 4,256 x 2,832 (L), 3,184 x 2,120 (M), 2,128 x 1,416 (S)
DX format (24 x 16) : 2,784 x 1,848 (L), 2,080 x 1,384 (M), 1,392 x 920 (S)
File Format NEF (RAW): 12 or 14 bit, lossless compressed, compressed, or uncompressed
TIFF (RGB)
JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8), or basic (approx. 1:16) compression ([Size priority]); [Optimal quality] compression available
NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats
Picture Control System Four setting options: Standard, Neutral, Vivid, Monochrome; each option can be adjusted
Storage Media CompactFlash (Type I, compliant with UDMA)
File System Compliant with DCF 2.0, DPOF, Exif 2.21, Pictbridge
Viewfinder SLR-type with fixed eye-level pentaprism
Diopter Adjustment 3 to +1 m-1
Eyepoint 18 mm (-1.0 m-1)
Focusing Screen Type B BriteView Clear Matte VI screen with superimposed AF points and framing grid lines
Frame Coverage Approx. 95% (vertical/horizontal)
Magnification Approx. 0.72x (50mm f/1.4 lens at infinity; -1.0 m-1)
Reflex Mirror Quick-return type
Depth-of-field Preview When CPU lens is attached, lens aperture can be stopped down to value selected by user (A and M modes) or value selected by camera (P and S modes)
Lens Aperture Instant-return type, with depth-of-field preview button
Compatible Lenses DX AF Nikkor: All functions supported
Type G or D AF Nikkor: All functions supported (PC Micro-Nikkor does not support some functions). IX Nikkor lenses not supported.
Other AF Nikkor: All functions supported except 3D Colour Matrix Metering II. Lenses for F3AF not supported
AI-P Nikkor: All functions supported except autofocus and 3D Colour Matrix Metering II
Non-CPU AI Nikkor: Can be used in exposure modes A and M; electronic rangefinder can be used if maximum aperture is f/5.6 or faster; Colour Matrix Metering and aperture value display supported if user provides lens data
Type Electronically controlled vertical-travel focal-plane shutter
Speed 1/8,000 to 30 s in steps of 1/3, 1/2 or 1 EV, Bulb, X250
Flash Sync Speed X = 1/250 s; synchronizes with shutter at 1/320 s or slower (flash range drops at speeds between 1/250 and 1/320 s)
Release Modes
  1. Single-frame [S] mode
  2. Continuous Low-speed [CL] mode
  3. Continuous High-speed [CH] mode
  4. Live View [LV] mode
  5. Self-timer [mark] mode
  6. Mirror-up [Mup] mode
Continuous Shooting Speed With Rechargeable Li-ion Battery EN-EL3e: 1-5 frames per second in [CL] mode, 5 fps in [CH] mode
With Multi-Power Battery Pack MB-D10 with batteries other than Rechargeable Li-ion Battery EN-EL3e or AC Adapter EH-5a/EH-5: 1-7 frames per second in [CL] mode, 8 fps in [CH] mode
Self-timer Electronically controlled timer with duration of 2, 5, 10 or 20 s
Metering TTL full-aperture exposure metering using 1,005-pixel RGB sensor
Metering System
  1. 3D Colour Matrix Metering II (type G and D lenses); Colour Matrix Metering II (other CPU lenses); Colour Matrix Metering (non-CPU lenses if user provides lens data)
  2. Centre-Weighted: Weight of 75% given to 8-, 12-, 15- or 20-mm circle in centre of frame, or weighting based on average of entire frame
  3. Spot: Meters 4-mm circle (about 1.5% of frame) centered on selected focus point (on centre focus point when non-CPU lens is used)
Metering Range
  1. 0 to 20 EV (Matrix or Centre-Weighted Metering)
  2. 2 to 20 EV (Spot Metering) (ISO 100 equivalent, f/1.4 lens, at 20°C/68°F)
Exposure Meter Coupling

Combined CPU and AI Exposure Modes
  1. Programmed Auto (P) with flexible program
  2. Shutter-Priority Auto (S)
  3. Aperture-Priority Auto (A)
  4. Manual (M)
Exposure Compensation ±5 EV in increments of 1/3, 1/2 or 1 EV
Exposure Lock Exposure locked at detected value with AE-L/AF-L button
Exposure Bracketing Exposure and/or flash bracketing (2 to 9 exposures in increments of 1/3, 1/2, 2/3 or 1 EV)
Sensitivity ISO 200 to 6400 in steps of 1/3, 1/2, or 1 EV; can be set to approx. 0.3, 0.5, 0.7, or 1 (ISO 100 equivalent) EV below ISO 200, or to approx. 0.3, 0.5, 0.7, 1 (ISO 12800 equivalent), or 2 (ISO 25600 equivalent) EV over ISO 6400
Active D-Lighting Can be selected from [Auto], [High], [Normal], or [Low]
Autofocus TTL phase-detection AF, 51 focus points (15 cross-sensors) by Nikon Multi-CAM 3500FX autofocus module; Detection: -1 to +19 EV (ISO 100 at 20°C/68°F); AF fine tuning possible; AF-assist illuminator (range approx. 0.5-3 m/1.6-9.8 ft.)
Lens Servo
  1. Autofocus: Single-servo AF (S); Continuous-servo AF (C); Focus Tracking automatically activated according to subject status
  2. Manual focus (M) with electronic rangefinder
Focus Point Single AF point can be selected from 51 or 11 focus points
AF-Area Mode
  1. Single-point AF
  2. Dynamic-area AF [number of AF points: 9, 21, 51, 51 (3D-Tracking)]
  3. Auto-area AF
Focus Lock Focus can be locked by pressing AE-L/AF-L button or by pressing shutter-release button halfway (Single-point AF in AF-S)
Built-in Flash Manual pop-up type; guide number of 17/56 (ISO 200, m/ft., 20°C/68°F) or 12/39 (ISO 100, m/ft., 20°C/68°F)
Flash Control
  1. TTL flash control with 1,005-pixel RGB sensor; i-TTL balanced fill-flash and standard i-TTL fill-flash available with SB-900, 800, 600 or 400
  2. Auto aperture (AA): Available with SB-900, 800 and CPU lens
  3. Non-TTL auto (A): Available with SB-900, 800, 28, 27 or 22s
  4. Distance-priority manual (GN): Available with SB-900, 800
Flash Sync Modes
  1. Front-curtain sync (normal)
  2. Slow sync
  3. Rear-curtain sync
  4. Red-eye reduction
  5. Red-eye reduction with slow sync
Flash Compensation -3 to +1 EV in increments of 1/3, 1/2 or 1 EV
Flash-ready Indicator Lights when Speedlight such as SB-900, SB-800, SB-600, SB-400, SB-80DX, SB-28DX, or SB-50DX is fully charged; blinks after flash is fired at full output
Accessory Shoe Standard ISO 518 hot-shoe contact with safety lock
Sync Terminal ISO 519 standard terminal
Nikon Creative Lighting System With Speedlights such as SB-900, SB-800, SB-600, SB-R200, or SU-800 (commander only), supports Advanced Wireless Lighting, Auto FP High-Speed Sync, Flash Colour Information Communication, modelling flash and FV lock; built-in flash can be used as a commander
White Balance Auto (TTL white balance with main image sensor and 1,005-pixel RGB sensor)
Seven manual modes can be preset with fine-tuning; colour temperature setting; white balance bracketing: 2 to 9 exposures in increments of 1, 2 or 3
Live View Modes Hand-held mode: TTL phase-detection AF with 51 focus areas (15 cross-type sensors)
Tripod mode: Contrast-detect AF on a desired point within a specific area
LCD Monitor 3-in., approx. 920,000-dot (VGA), 170-degree wide-viewing-angle, 100% frame coverage, low-temperature polysilicon TFT LCD with brightness adjustment
Playback Function Full-frame and thumbnail (4 or 9 images) playback with playback zoom, slide show, histogram display, highlight display, auto image rotation, and image comment (up to 36 characters)
USB Interface Hi-Speed USB
Video Output NTSC or PAL; simultaneous playback from both the video output and on the LCD monitor available
HDMI Output Supports HDMI version 1.3a; Type C mini connector is provided; simultaneous playback from both the HDMI output terminal and on the LCD monitor not available
Ten-pin Terminal
  1. GPS: NMEA 0183 (Ver. 2.01 and 3.01) interface standard supported with 9-pin D-sub cable and GPS Cable MC-35 (optional)
  2. Remote control: via Ten-pin terminal
Supported Languages Chinese (Simplified and Traditional), Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish
Battery One Rechargeable Li-ion Battery EN-EL3e
Battery Pack Multi-Power Battery Pack MB-D10 (optional) with one Rechargeable Li-ion Battery EN-EL4a/EN-EL4 (battery chamber cover BL-3 required) or EN-EL3e, or eight R6/AA-size alkaline (LR6), Ni-MH (HR6), lithium (FR6) batteries, or nickel-manganese (ZR6) batteries
AC Adapter AC Adapter EH-5a/EH-5 (optional)
Tripod Socket 1/4 in. (ISO 1222)
Dimensions (W x H x D) Approx. 147 x 123 x 77 mm/5.8 x 4.8 x 3.0 in.
Weight Approx. 995 g/2.19 lb. without battery, memory card, body cap or LCD monitor cover
Temperature 0-40°C/32-104°F
Humidity Under 85% (no condensation)
Supplied Accessories* Rechargeable Li-ion Battery EN-EL3e, Quick Charger MH-18a, USB Cable UC-E4, Video Cable EG-D100, Camera Strap AN-D700, Body Cap BF-1A, Accessory Shoe Cover BS-1, LCD Monitor Cover BM-9, Software Suite CD-ROM

*Supplied accessories may differ depending on country or area
Main Optional Accessories Wireless Transmitter WT-4, Magnifying Eyepiece DK-17M, AC Adapter EH-5a, Capture NX 2 Software, Camera Control Pro 2 Software, Image Authentication Software
