| No.
of Effective Pixels (Camera) |
Approximately
9.29 million pixels |
| Image
Sensor |
1/2.3-inch
CMOS (total pixels: approx. 10.29 million pixels) |
| Lens |
Focal
length |
f=4.9-52.5mm
(equivalent to 28-300 mm for 35 mm film cameras. With Step Zoom
set, option of eight fixed lengths: 28 mm, 35 mm, 50 mm, 85 mm,
105 mm, 135 mm, 200 mm, and 300 mm) |
| F-aperture |
F3.5
(Wide) - F5.6 (Telephoto) |
Shooting
Distance |
Normal
shooting: Approx. 30 cm - infinity (Wide), approx. 1.5 m -
infinity (Telephoto) (from the front of the lens)
Macro: Approx. 1 cm - infinity (Wide), approx. 28 cm - infinity
(Telephoto), approx. 1 cm - infinity (Zoom Macro) (from the
front of the lens) |
| Lens
Construction |
10
elements in 7 groups (aspheric lens: 4 elements and 5 surfaces) |
| Zoom
Magnification |
Optical:
10.7x zoom (equivalent to 28-300 mm focal length for 35 mm
cameras)
Digital: 4.8x up to 51.4x (equivalent to 1440 mm) when used with
optical zoom
Auto Resize: 5.4x*1 up to 57.8x*1
(equivalent to 1620 mm) when used with optical zoom |
| Focus
Mode |
Multi
AF (contrast AF method) / Spot AF (contrast AF method) /
Continuous AF / Multi-Target AF / Manual Focus / Fixed Focus
(Snap) / Infinity (AF auxiliary light) |
| Image
stabilizer |
sensor shift method image stabilizer |
| Shutter
Speed*2 |
Still
image |
8,
4, 2, 1 - 1/2000 sec. |
| Movie |
1/30
- 1/2000 sec. |
| Continuous
Shooting |
Continuous
shooting speed*3 |
approx.5
frames/sec. (F3456, F3:2, F1:1 shooting time; shooting speed
after 30 pictures is approx. 3 frames/sec.) |
| Continuous
shooting capacity |
999
pictures |
| Exposure
Control |
Exposure
Metering Mode |
Multi
(256 segments), Center Weighted Light Metering, Spot Metering |
| Exposure
Mode |
Program
AE |
Exposure
Compensation |
Manual
Exposure Compensation +/-2.0EV (1/3EV Steps), Auto Bracket
Function (-0.5EV, ±0, +0.5EV) |
| ISO
Sensitivity (Standard Output Sensitivity) |
AUTO,
AUTO-HI, ISO80 / ISO100 / ISO200 / ISO400 / ISO800 / ISO1600 |
| White
Balance Mode |
AUTO
/ Multi-Pattern AUTO / Outdoors / Cloudy / Incandescent /
Incandescent 2 / Fluorescent / Manual, White Balance Bracket
Function |
| Flash |
Built-in
flash mode |
Auto
(during low light and when the subject is backlit),
Red-eye-Reduction, Flash On, Slow Synchro, Flash Off |
| Built-in
flash range |
Approx.
20 cm - 3.0 m (Wide), approx. 28 cm - 4.0 m (Telephoto) (ISO
Auto/ISO 800, from the front of the lens) |
| Flash
compensation |
+/-2.0EV
(1/3EV Steps) |
| Monitor |
3.0-inch
Transparent LCD (approx. 920,000 dots) |
| Shooting
Mode |
Auto
Shooting Mode / Easy Shooting Mode / Dynamic Range Double Shot
Mode / Continuous Shooting Modes (Continuous, M-Continuous Plus,
Ultra-High-Speed Continuous) / Scene Modes (Portrait / Sports /
Night Portrait / Landscape / Nightscape / High Sensitivity /
Zoom Macro / High-Contrast B&W / Miniaturize / Skew
Correction / Text) / My Setting Mode / Movie Mode |
| Picture
Quality Mode*4 |
F
(Fine) / N (Normal) |
| No.
of Pixels Recorded |
Still
image/multi-picture |
[4:3]
3456 x 2592, 3072 x 2304, 2592 x 1944, 2048 x 1536, 1728 x 1296
(M-Cont Plus), 1280 x 960, 640 x 480
[3:2] 3456 x 2304
[1:1] 2592 x 2592 |
| Movie |
640
x 480, 320 x 240 |
| Text |
3456
x 2592, 2048 x 1536 |
| Recording
Media |
SD
memory card (32, 64, 128, 256, 512 MB, 1GB, 2GB), SDHC memory
card (4GB, 8GB, 16GB, 32GB), Internal memory (approx. 88MB) |
| Storage
Capacity (Pictures/ Time):*5 (internal memory approx.
88MB) |
Still
image/multi-picture |
3456
x 2592 (F: 24, N: 42) / 3456 x 2304 (F: 27) / 2592 x 2592 (F:
33) / 3072 x 2304 (N: 53) / 2592 x 1944 (N: 72) / 2048 x 1536
(N: 109) / 1728 x 1296 (N: 143)(M-Cont Plus) / 1280 x 960 (N:
175) / 640 x 480 (N: 705) |
| Movie*6 |
640
x 480: 15 frames / sec. (1 min. 42 sec.), 320 x 240: 15 frames /
sec. (4 min. 19 sec.) / 640 x 480: 30 frames / sec. (51 sec.),
320 x 240: 30 frames / sec. (2 min. 12 sec.) |
| Recording
File Format |
Still
Image |
JPEG(Exif
ver.2.21)*7 |
| Multi-picture |
CIPA
DC-X007-2009 Multi-Picture Format |
| Movie |
AVI
(Open DML Motion JPEG Format compliant) |
| Compression
method |
JPEG
Baseline method compliant |
| Other
Major Shooting Functions |
Continuous,
Self-Timer (operation time: approx. 10 sec. / approx. 2 sec. /
custom self-timer), Interval Timer (Shooting interval: 5 sec. -
1 hour (5 sec. steps)*8, Color Bracket function,
Focus Bracket function, AE/AF Target Shift, Histogram, Grid
Guide, Electronic Level |
| Other
Major Playback Functions |
Grid
View, Enlarged Display (maximum 16x), Resize, Level
Compensation, White Balance Compensation, Trim, Flag, Slideshow,
DPOF Setting |
| Interface |
USB
2.0 (High-Speed USB) Mini-B, Mass storage compatible*9
/ AV Out 1.0Vp-p (75Ω) |
| Video
Signal Format |
NTSC,
PAL switchable |
| Power
Supply |
Rechargeable
Battery: DB-70 x1, AC adapter (AC-4g option) |
| Battery
Consumption*10 |
Based
on CIPA Standard: Using the DB-70, approx. 290 pictures (when
LCD Dim is on)*11 |
| External
Dimensions |
101.5
mm (W) x 58.3 mm (H) x 29.4 mm (D) (excluding projecting parts) |
| Weight |
Approx.
185 g (excluding battery, SD memory card, strap), Accessories
approx. 23 g (battery, strap) |
| Operating
Temperature Range |
0°C
- 40°C |
