Ricoh GR Digital II Camera

£299

also GRD II Viewfinder £100

Imaging Sensor 1/1.75" primary-colour CCD with 10.01 million effective pixels
(total pixels: 10.3 million)

Lens
Focal length 5.9 mm (equivalent to 28mm on a 35mm camera)
F-aperture F2.4 to F11 (+F7.1 in auto mode is with ND filter)
Shooting distance Approx. 30cm from lens tip to infinity
Approx. 1.5cm from lens tip to infinity (macro)
Lens construction 6 elements in 5 groups (two aspherical lenses/three aspherical surfaces)

Digital Zoom Magnification
Approx. 4.0X digital zoom. Approx. 5.7X auto-resize zoom (VGA images)

Focus Mode
Multi AF (CCD method)/Spot AF (CCD method)/Manual focus/nap/Infinity
(focus lock and AF auxiliary light also available)
Shutter Speed [1]
Still image 180, 120, 60, 30, 15, 8, 4, 2, 1 to 1/2000 sec.
Movie 1/30 to 1/2000 sec.

Exposure Adjustment
Exposure Multi Light Metering (256 segments), Centre-weighted Light Metering,
metering mode Spot Metering (TTL-CCD Metering Method, AE lock available)

Exposure mode
Programme shift AE/Aperture priority AE/Manual exposure

Exposure Manual compensation (+2.0 to -2.0 EV in 1/3 EV steps),
compensation Auto bracket function (-0.5 EV, ±0, +0.5 EV / -0.3 EV, ±0, +0.3 EV)

ISO sensitivity
AUTO/AUTO-HI/ISO80/100/200/400/800/1600
(Standard Output Sensitivity)

White Balance Mode
Auto/Outdoors/Cloudy/Incandescent Lamp/Fluorescent Lamp/
Manual Settings/Detail,
White balance bracket function
Flash Flash mode Auto (fires automatically when subject poorly lit or in backlight situations)/
Red-eye/
Flash On/Flash Synchro/Flash Off

Built-in flash range Approx. 20 cm to approx. 3.0 m (ISO AUTO)

Flash compensation ±2.0 EV (1/3 EV steps)

Picture Display
2.7-inch Transparent Amorphous Silicon TFT LCD, approx. 230,000 pixels

Shooting Mode
Auto Shooting Mode/Program Shift Mode/Aperture Priority Mode/
Manual Exposure
Mode/Scene Mode (skew correct/text/movie)/My Settings Mode
Picture Quality Mode [2] F(Fine)/ N(Normal) / RAW (DNG file format) [3]

Number of Recorded Pixels
Still image 3648 x 2736, 3648 x 2432, 2736 x 2736, 3264 x 2448, 2592 x 1944,
2048 x 1536, 1280 x 960, 640 x 480
Movie 640 x 480, 320 x 240
Text 3648 x 2736, 2048 x 1536

Recording Media
SD memory card, SDHC card, Multi media card, Internal memory (approx. 54MB)

Storage Capacity/Time [4] Still
3648 x 2736 (RAW: 2, F: 14, N: 24), 3648 x 2432 (RAW: 3, F: 15, N: 27),
(Built-in approx. 54 MB storage) 2736 x 2736 (RAW: 3, F: 18, N: 32), 3264 x 2448 (N: 30),
2592 x 1944 (N: 47), 2048 x 1536 (N: 73), 1280 x 960 (N: 133), 640 x 480 (N: 497)
Movie [5] 640 x 480 @ 30 frames/sec. (41 sec.),
640 x 480 @ 15 frames/sec. (1 min 22 sec.),
320 x 240 @ 30 frames/sec. (1 min 22 sec.),
320 x 240 @ 15 frames/sec. (2 min 40 sec.)

Recording File Formats
Still JPEG (Exif ver2.21) [6], RAW (DNG)
Movie AVI (Open DML Motion JPEG Format Compliant)

Other Major Shooting
Continuous/S-Cont/M-Cont, Self-Timer (delay: approx. 10 sec./ approx. 2 sec.),
Function Interval (shooting interval: 5 sec. to 3 hrs. in 5-sec. intervals) [7], Color Bracket,
B&W(TE), Colour Space Set, Noise Reduction, Histogram Display, Grid Guide
Display, Depth of Field Display, Enlarge Photo Icon, Electronic Level, Hot Shoe

Other Major Playback Function
Auto Rotate, Three-frame View/Grid View, Magnifying (up to 16X), Resize

Interface
USB2.0 (High-Speed USB) Mini-B cable, Mass storage [8], AV output

Video Signal Format
NTSC, PAL switchable

Power Source
Rechargeable Battery (DB60) x 1, AC Adapter (AC-4c option),
AAA Alkaline Batteries x 2, AAA Oxyride Batteries x 2?
AAA Nickel-Hydrogen Batteries x 2
Battery Consumption [9]
When CIPA-standard compliant DB60 used: approx. 370 pictures
When AAA alkaline batteries used: approx 45 pictures [10]

Dimensions
107.0 mm x 58.0 mm x 25.0 mm (W x H x D); does not include protruding parts

Weight
Camera: Approx. 168 g (excluding battery/SD memory card/strap);
Accessories: Approx. 30 g (battery/strap)

Operating temperature
0ºC to 40ºC

1. Maximum and minimum shutter speeds differ by shooting mode and flash mode.
2. Image-quality modes that can be set differ depending on the image size.
3. Simultaneous recording of a JPEG in Fine/Normal or Normal640 mode at the same size as the RAW image.
DNG is a type of RAW image file format. It is a standard file format advocated by Adobe Systems.
4. Estimated number of shots/time that can be recorded.
5. Up to 90 min. or 4 GB can be recorded in one shot.
6. DCF compliant; DPOF supported.
DCF is an abbreviation for Design rule for Camera File system standardized by JEITA.
(Full compatibility between devices not guaranteed.)
7. With Flash off.
8. Mass storage supports Windows Me/2000/XP/Vista and Mac OS 9.0 to 9.2.2/Mac OS X 10.1.2 to 10.4.9.
9. The numbers of photos that can be taken were measured using conditions compliant with the CIPA standard.
Actual number of photos that can be taken will differ greatly depending on conditions of use.
10. AAA alkaline dry-cell batteries made by Matsushita Battery Industrial Co., Ltd. were used

Item Description Imaging device 1/1.8 primary color CCD with 8,130,000 effective pixels (total pixels: 8,300,000) Lens <Focal distance> f=5.9 mm (28 mm converted to 35mm format camera) <Brightness (F)> F 2.4 to F 11*1 <Lens composition> 6 elements; 5 groups: 7 diaphragm blades Digital zoom 4.0x Shooting range About 0.3 m to infinity from lens tip Macro shooting range About 0.015 m to infinity from lens tip Shutter <Stil> 180, 120, 60, 30, 15, 8, 4, 2, 1 - 1/2,000 sec. <Video> 1/30 -1/2,000 sec. Pixels <Still> 3,264 x 2,448; 3,264 x 2,176; 2,592 x 1,944; 2,048 x 1,536; 1,280 x 960; 640 x 480 <Text> 3,264 x 2,448; 2,048 x 1,536 <Video> 320 x 240; 160 x 120 Picture-quality modes*2 F (Fine)/N (Normal)/RAW*3 ISO sensitivity*4 AUTO; 64; 100; 200; 400; 800; 1,600 Flash Auto/ redeye suppression/ force flash/ slow synchro/ flash off Throw distance*5 approx. 0.2 to 3 m Focus Autofocus/ manual focus/ snap/ infinity (AF supplemental light also available) Exposure adjustment TTL-CCD photometric system: multi (256 div.)/ center focus photometry/ spot photometry Exposure compensation Manual correction (+2.0 to -2.0 EV 1/3 EV steps); auto bracket feature (-0.5 EV; ±0; +0.5 EV) White balance Auto; fixed (Daylight/ Overcast/ Tungsten Light/ fluorescent light/ manual/ advanced); white balance bracket feature Recording media SD memory card (3.3V 32/ 64/ 128/ 256/ 512MB/ 1GB); multimedia card; built-in memory (26 MB) Storage capacity*6 (built-in 26 MB storage) <Still> 3,264 x 2,448: RAW: 1/F: 8/ N: 14; 3,264 x 2,176: RAW: 1/F: 9; 2,592 x 1,944: N: 22; 2,048 x 1,536: N: 36; 1,280 x 960: N: 63; 640 x 480: N: 277 Storage time (built-in 26 MB storage) <Video> 320 x 240: 39 sec (30 frames/sec); 160 x 120: 2 min 26 sec (30 frames/sec)*7 <Audio> 56 min 45 sec*8 Storage data capacity <Still> 3,264 x 2,448: RAW: about 11.52 MB/screen; F: about 2.83 MB/screen; N: 1.63 MB/screen 3,264 x 2,176: RAW: about 10.25 MB/screen; F: about 2.57 MB/screen; 2,592 x 1,944: N: about 1.03 MB/screen; 2,048 x 1,536: N: about 672 KB/screen;1,280 x 960; N: about 356 KB/screen; 640 x 480: N: about 83KB/screen Recording modes Photo (Still, Continuous, S-Continuous, M-Continuous), Program shift/ Aperture-Priority/ Manual exposure, Scene (Text, Sound), Motion Recording formats <Still> compression: JPEG*9 (Exif ver. 2.21); RAW(DNG)*10 <Text> TIFF (MMR format/ITU-T.6) <Video> AVI (Open DML Motion JPEG format compliant) <Audio> WAV (Exif ver. 2.21 μ law) LCD monitor 2.5 inch low-noise polysilicon TFT LCD; about 210,000 pixels Self timer Operating time: about 10 sec/ 2 sec Interval timer Shooting interval: 5 sec. to 3 hours (units of 5 sec.)*11 PC interface USB 2.0; Ricoh original mass storage selectable*12 AUDIO/ VIDEO interface Audio OUT/ Video OUT Video signal format Switch between NTSC & PAL Dimensions 107.0 x 25.0 x 58.0 mm (WxDxH); does not include protruding parts Weight About 170 g (not including battery/ SD memory card/ strap); supplied parts: 30g (battery/ strap) Power 1 Rechargeable battery (DB-60); AC adapter (AC-4c option); 2 AAA alkaline dry-cell batteries 2 AAA Oxyride dry-cell batteries; 2 AAA nickel-hydrogen dry-cell batteries Shooting capacity *13 CIPA-standard compliant DB-60 used: about 250; When AAA alkaline dry-cell battery used: about 30*14 Temp. range for use 0°C to 40°C
